Chicago Pneumatic has added our range of electric portable - CPS E Air Compressors
Why Choose E-Air?
Why did we launch this product?
The CP E-Air Range of Compressors offers our customers an option to avoid having to refill diesel engine fluid and diesel fuel for compressors that are being used for long-term rentals. At the same time, these electric compressors cost less to operate and service.
This range of compressors combines smart engineering, time-tested technology, and quality components that all add up to a solution with extreme versatility--suitable for a wide range of applications.
The E-Air compressors offered by CP are loaded with many standard features and benefits.
Loaded with Features and Benefits.
| Features | Benefits |
| Electric Motor Driven | No Diesel Fuel needed/Increased reliability |
No Exhaust Emissions |
Can be Operated Indoors |
| No Engine Service | Fewer Maintenance items and Lower Service Costs |
| Compact Encloser | Take less space |
| Built to be moved frequently | Heavy Duty Skid Base |
| Light-weight | Single Point Lifting Bale/Easier to move around |
| Environmental Enclosure | Sound suppressed and 110% Fluid Containment |
| Cam Lock Connections | Easier to Install |
| Simple Analog Control Panel | Easier to Operate and Troubleshoot |
| Soft Start Controller | Fewer Amps requires to start the Compressor |
| After cooler standard | Cools the Air and Water Separator Removes Moisture |
| Bypass on After Cooler | For operating the compressor at temperatures below 32° F |
| Cold Weather Package | Allows the compressor to be used down to -13° F |
CPS 400E
400 CFM 100-150 PSI
CPS 500E
500 CFM 100-150 PSI
CPS 900E
900 CFM 100-150 PSI
The Main Benefits of CP Electric Compressors
More Uptime.
- Robust and Reliable
- (C3 class painting will protect the canopy during the life-time)
- Fewer Service Interventions
- 1000 hr. service on air filters in normal environments.
- 2000 hrs/2 year service interval.
- Big doors for easy access to all service points.
- Interchangeable consumables with diesel driven.
Engineered, Not Assembled
- Compact Design
- Reduces installation space required
- Reduces shipping cost (skids shipped side by side on trucks)
- Based on competition range analysis, CPS E900-150 is 50% smaller and 33% lighter than competitors units
- Lower Noise Level
- Soft started - Low starting current amps
Solutions, not compromise.
- Heat Tracing for Water Separator & Unloader Valve
- Heated Control panel CSA/UL for -13° operations
- Cam Locks
- Thermostatic bypass valve as standard.
- Spill Containment
Efficient, not wasteful.
- Electric motors high-efficiency IE3
- Saving of $23,000 vs diesel driven units every 1000 h
- 54% Energy cost saving
Customer First Philosophy
- Ready to operate on-site conditions
- Indoors or outdoors
- Concrete base not required
- Cam locks for quick installation
- Main breaker standard
- Operates from: -13° to 122° F
- The E-Air compressors are built with heavy-duty frames, sound-suppressed enclosures, and lifting structures.
- The size of the E-Air units on average are 50% smaller than a comparable diesel unit.
- The E-Air compressors are specifically designed for construction site conditions
- Spillage-free frame standard
Main Technical Data
| F.A.D. (ISO1217) | 900 cfm | 500 cfm | 400 cfm |
| Working pressure | 150 🡪 100 psi | 150 🡪 100 psi | 150 🡪 100 psi |
| Rated voltage available - line to line | 460 V | 460 V | 460 V |
| Drive motor power | 160 kW | 90 kW | 75 kW |
| Frequency | 60 Hz | 60 Hz | 60 Hz |
| Main motor Premium efficiency | IE3 (96%) | IE3 (96%) | IE3 (96%) |
| Sound pressure @ 7m | 73 | 73 | 73 |
| Air outlet (1 x 1 1/2" & 3 x 3/4" Outlets.) |
With Aftercooler and water separator | With Aftercooler and water separator | With Aftercooler and water separator |
| Electrical components & Cubicle | UL - us | UL - us | UL - us |
| Motor Premium efficiency | NEMA Premium UL - us | NEMA Premium UL - us | NEMA Premium UL - us |
| F.A.D. (ISO1217) | ASME/ CRN | ASME/ CRN | ASME/ CRN |
Energy Consumption Table
| Compressor 900cfm @ 150psi | Energy consumption full load | Energy cost (USD) | Total cost for 1000h during one year | |||
CPS E900 |
194 | kWh | 0,10 | USD/kWh | $19,400 | 54% |
CPS 900 JD |
10.6 | gal/h | 4,00 | USD/ Gal | $42,400 | |
What are some differences between
CPS Electric Compressors & the competition?
CPS Electric Compressors & the competition?
- High-Efficiency oil flooded rotary screw compressor
- Easy Serviceability & Easy Regulating System
- Compressor has 2,000 hr service intervals
- Controls that work from 122° F to -13° F
- High-Efficiency oil flooded rotary screw compressor
- Easy Serviceability & Easy Regulating System
- Compressor has 2,000 hr service intervals
- Controls that work from 122° F to -13° F
- Some competitors list higher CFM ratings than they can deliver
- Complicated Regulator System
- Analog controls are only good for operations at above 33° F
- No spill free frame
- Electric industrial air compressors are not designed or built structurally to be frequently moved
- Some competitors list higher CFM ratings than they can deliver
- Complicated Regulator System
- Analog controls are only good for operations at above 33° F
- No spill free frame
- Electric industrial air compressors are not designed or built structurally to be frequently moved
FAQ
What am I paying for?
The initial purchase price for the AP E-Air units is higher than a standard industrial compressor.
The higher price is because we've added additional features that are not normally required or offered on an industrial stationary compressor.
What about flow & pressure settings?
The rated airflow from the CP E-Air compressors are measured according to ISO 1217, 2009 annex D.
What about the installation?
The CPS E Air compressors are designed and built for rental. We have all of the following features: Cam Lock Connections, Analog Control, Main Breaker, Soft Start Motor Control, NEMA 4 Control Enclosure, Reinforced Base, Lithium Connection, and 110% Fluid Containment.
These features all help for quick installations, plus offer a trailer package option for even more flexibility.
What about temperature?
The CPS E-Air units all come standard with a cold weather package that allows for operation down to -13° F.
